| Mechanical & Environmental Characteristics | |
| Packaging | Rugged, hard-shell transit case |
| Storage Temperature | -40℃ to +85℃ |
| Operating Temperature | -40℃ to +85℃ |
| Humidity | 0 to 95%, non-condensing |
| Fiber & Connector Characteristics | |
| Fiber Types | G657A/G652D |
| Fiber Length | 500m/1000m/1500m |
| Typical Loss | <0.36dB @ 1310 for 1000 meters <0.22dB @ 1310 for 1000 meters |
| Connector Type | SC |
| Polish | UPC/APC |
| Return Loss | UPC>=50dB, APC>=60dB, PC>=35dB |
| Repeatability (dB) | <=0.2 (1000 times) |
| Exchangeability (dB) | <=0.2 |
Feature & Application
- Pulse Suppressor, Launch Box, Delay Line, Installation/Testing, Training, Calibration
- Compound Latch for positive seal and easy opening with locking feature.
- Nonmetal construction will not dent, corrode, or conduce electricity
- Water and dust proof allowing the unit to be taken into almost any environmen
- Auto Purge Valve for changes in altitude and temperature
